WIND TOWER IN/OUT SIDE SHOT BLAST MACHINE
- AIR BLAST has lower power efficiency than IMPELLER BLAST using centrifugal force and its cost is about 3 times higher than that of centrifugal blast when processing the wind tower. Because of this reason, we have only used AIR BLAST in wind tower processing in the past.
However, we have developed the automatic centrifugal blast machine for the first time in Korea maximizing the advantages of centrifugal blast, thus achieving equalization of product quality and reducing the production cost. (Our products are applied the patent)
- Processing Method: Inner and outer surfaces are processed by simultaneously by centrifugal projectors(impellers).
- Cleanliness: Based on Sa 2
Specification
APPLICABLE SIZE (mm) |
Φ1,600x27,000(L) |
Φ3,500x27,000(L) |
Φ4,300x30,000(L) |
Φ7,100x30,000(L) |
Vaccum recovery |
WORK TIME |
30 min |
65 min |
90 min |
150 min |
100㎥/min |
|
STIO-4300 INTERNAL(Insiede diameter) |
STIO-4300 EXTERNAL(Outside diameter) |
IMPELLER |
Ø520x85W |
Ø520x85W |
MOTOR POWER |
Ø520x85W |
Ø520x85W |
MOTOR POWER |
100HP |
75HP |
AIR BLAST UNIT |
Purpose of TOUCH –UP |
SHOT collector |
VACUUM RECOVERY SYSTEM |
Dust collector |
200~300㎥/min |
Above application is just an example.
Please consult us for the detailed specifications according to your materials and work conditions.
- Relevant photo-cuts
